80-10m EFHW
Description
This 80-10m End-Fed Half-Wave (EFHW) antenna was my first HF antenna installation after obtaining my amateur radio license in April 2025. It is a ready-made, commercially purchased 8-band version that covers the 80, 40, 30, 20, 17, 15, 12, and 10 meter bands.
The EFHW design offers several advantages for a first HF antenna: it requires only a single support point, can be deployed in various configurations (horizontal, sloper, or inverted-L), and typically operates without requiring an antenna tuner across its design bands. This makes it an excellent choice for getting on the air quickly while learning HF operations.
Supplier Information
Product: HyEndFed 8 Band 1KW SSB AL Plate (80/40/(30)/20/17/15/12/10m)
Supplier Link: hyendcompany.nl product page
- 8-band coverage: 80/40/(30)/20/17/15/12/10 meters
- Max power: 1000 W PEP SSB, 200 W digital
- Wire length: 40 meters
- Enclosure: Polycarbonate IP67, 100% UV resistant
- SO-239 Teflon connector
- All hardware stainless steel
- Optional transformer optimized for 80m (better SWR on 80m, typical 1:2.5 SWR on 10m)
- Capacitor options for 80m resonance: 3.7 MHz or 3.9 MHz
- Open field, 10 m height, horizontal
- 4.5 m coax to line isolator, then 10 m Ecoflex 10 to analyzer
- Network box 10 m above ground; 40 m wire to 10 m mast
- Not grounded; VSWR meter: RigExpert AA-600
SWR Curves
SWR curves provided by HyEnd Company.
Supplier Photos
